PV complete-set equipment
Prefabricated PV Step-up Substation
Move from inverter output to the medium-voltage collection system with a coordinated enclosure, interface and document review.
Purchase readiness
Move from product interest to a review-ready request.
Pricing is confirmed per configuration and quotation. Project builds are engineered to spec; final ratings, documents and delivery are confirmed before quotation.
- MOQ
- 1 unit
- FOB
- Ningbo / Shanghai
- Standard lead time
- 3-5 days
- Project lead time
- 5-30 days
- Sample route
- 3-5 days
Get a configuration quote Prefabricated PV Step-up Substation
System inputArray, inverter or electrical drawing
ConfigurationScope checked before quotation
Document basisDrawing, BOM and required records
Project reviewTechnical details aligned before release
Review point 01
Multiple suppliers leave the transformer and switchgear interfaces unclear.
Review the inverter output, transformer duty, HV/LV arrangement and cable interfaces as one configured package.
- Electrical design and interfaces
- Installation and enclosure conditions
- Document package before release
Review point 02
Outdoor installation creates enclosure, access and thermal questions.
Confirm enclosure construction, environmental conditions, ventilation, service clearance and cable entry before release.
- Electrical design and interfaces
- Installation and enclosure conditions
- Document package before release
Review point 03
A quotation is not enough for the installation team.
Agree the drawing, BOM, interface details and inspection/document list that will accompany the project.
- Electrical design and interfaces
- Installation and enclosure conditions
- Document package before release
Product range
Start with the family that matches the system requirement.
Model, rating and component choices are confirmed from approved project inputs.
02
Dry-type package
AN/AF transformer arrangement where the installation context requires it
Confirm ventilation and enclosure layout
03
Pad-mounted compact package
Space-efficient outdoor enclosure with defined HV/LV access
Confirm foundation and cable route
04
Smart monitoring package
Optional temperature, door, gas and communication interfaces
Confirm protocol and monitoring ownership
Technical scope
Specifications structured for a project review.
| Typical capacity range | 1000 / 1600 / 2000 / 2500 kVA starting points |
|---|---|
| LV / HV side | 0.4 / 0.69 / 0.8 kV to 10 / 35 kV starting points |
| Transformer and MV unit | Oil-immersed or dry-type; RMU or VCB interface as required |
| Enclosure | Outdoor enclosure, cable entry, ventilation and service access defined by site conditions |
| Monitoring | Optional temperature, door, gas and RS485 / Ethernet / 4G interfaces |
| Reference standards | IEC 60076 / IEC 62271-200 / IEC 61439 / GB/T 17467 |
| Release package | GA, SLD, BOM, wiring/interface and inspection records as required |
Applications
Make the product conversation fit the operating context.
Utility-scale solar
EPC, IPP and power project teams
PV inverter output to medium-voltage collection interface
Commercial rooftop PV
Industrial site owners and integrators
Compact package around site footprint and cable entry
PV-plus-storage
Renewable project developers
Coordinated transformer, distribution and monitoring interfaces
System position
Keep the handoff clear from solar generation to the grid.
01PV array and inverter
02LV output review
03Step-up substation
04MV collection / grid
The exact equipment boundary, interfaces and protection responsibility are confirmed against the approved single-line diagram.
Application profiles
One product family, reviewed around the installation context.
The photographs show the operating context used in a technical discussion. Project-specific equipment, site evidence and final configuration are confirmed in the quotation package.
Application profile
Utility-scale solar
Review voltage, footprint, cable entry, access and document requirements for this context.
Application profile
C&I and rooftop packages
Review voltage, footprint, cable entry, access and document requirements for this context.
Application profile
PV-plus-storage systems
Review voltage, footprint, cable entry, access and document requirements for this context.
Technical resources
Get the documents that move the review forward.
Catalogue
Product catalogue
Overview material for comparing the family and identifying the next technical question.
Request through project inquiry ->Technical packDatasheet and GA drawing
Model-level files matched to the confirmed configuration and revision.
Request through project inquiry ->Project setOEM / project document set
Define the BOM, interface, inspection and handover documents for the workflow.
Request through project inquiry ->Related product families
Continue the system review.
PV complete-set equipment
Ring main unit (RMU)
Keep the medium-voltage ring, protection, cable interfaces and remote-control path clear from the first project review.
Solar PV distribution
Solar PV equipment
Make every string, protection point and downstream interface easier to review before the quotation is released.
Low-voltage distribution
LV switchgear
Move from a cabinet name to a buildable distribution arrangement with the right interfaces, access and documentation.
Energy storage integration
Energy storage control
Bring BMS, PCS, EMS, protection and communications into one reviewable control scope.
FAQ
Questions buyers usually ask before sending an RFQ.
What capacity can the prefabricated substation support?
The planning range starts at 1000, 1600, 2000 and 2500 kVA. Final capacity, transformer duty and protection arrangement are confirmed from the inverter output, site conditions and project documents.
Can the low-voltage and high-voltage sides be customized?
Yes. The starting points are 0.4 / 0.69 / 0.8 kV on the LV side and 10 / 35 kV on the HV side; the final interface follows the approved project design.
Can oil-immersed and dry-type transformers both be considered?
Both can be reviewed. The choice depends on installation environment, cooling, access, fire strategy, maintenance and the approved project specification.
What should be sent for an initial review?
The inverter output, target capacity, HV/LV voltage, single-line diagram, installation environment, quantity, destination and document requirements provide the best starting point.
Can the configuration be adapted to our project drawing?
Yes. The product-family page is a starting point. Final enclosure arrangement, component selection, interfaces and documentation are confirmed against the approved drawing, load schedule or technical brief.
What should we send for a useful first quotation?
A single-line diagram, target ratings, quantity, installation environment, delivery destination and any required standards or document list will help the engineering review start with the right assumptions.
Can NEUTRON support OEM or project-specific assembly?
The review can include OEM, drawing-led assembly and project-specific integration requirements. Scope, interfaces, inspection points and document ownership are agreed before release.
Are the figures on this page a final product datasheet?
No. This page explains the product family and the information needed for selection. The approved datasheet, drawing and quotation are the controlling documents for a specific project.
